The ABB DATX110, also cataloged as the DATX110 Data Transfer Module, operates as a dedicated hardware component for drive-to-controller communication routing within ABB ACS800 and ACS880 drive series networks.
Hardware Specifications
Parameter
Specification
Model
DATX110
Brand
ABB
Origin
Sweden
Weight
250 g
Dimensions
40 mm x 100 mm x 120 mm (W x H x D)
Panel Cutout Size
110 mm x 90 mm
Housing Material
Metal
Operating Temp
0 to +55 deg C (Standard industrial baseline)
Power Supply Voltage
24 VDC +/-10%
Current Consumption
< 100 mA
Modbus RTU Interface
RS-485
Modbus ASCII Interface
RS-232
Fieldbus Interfaces
Profibus DP, DeviceNet, CANopen (M12 connectors)
Diagnostic Indicators
Front-facing LEDs
Product Type
Data Transfer Modules
Backplane Bus Communication Velocity and Network Determinism
The DATX110 executes asynchronous-to-deterministic protocol conversion to tie industrial variable speed drives directly into high-level automation networks. The internal data engine handles protocol serialization for Modbus RTU, Profibus DP, and CANopen, regulating transmission buffers to maintain predictable execution cycles without introducing packet jitter to the master controller loop. It ensures fixed frame transmission latency over Ethernet and serial links while preserving complete firmware flash compatibility with the processing baselines of ACS800 and
