The ABB BDFC-01C Fan Control Panel is a digital frequency converter program designed for ACS880 (frame R8i) converter modules. It provides flexible braking control by allowing multiple modules to connect in parallel, increasing braking power and system efficiency.
Compact dimensions of 23.3×18.3×5.3 cm and a lightweight 0.6 kg build make the BDFC-01C easy to integrate into ABB drive systems.
Technical Specifications
Parameter
Value
Model Number
BDFC-01C
Module Type
Fan Control Panel
Manufacturer
ABB
Product Range
ABB
Dimensions
23.3 × 18.3 × 5.3 cm
Weight
0.6 kg
Control Unit
UCU-x2
Modulation Frequency
1 kHz
Phase Shift
120°
Monitoring Parameters
Phase currents, DC voltage, module & ambient temperature
Protection Features
DC overvoltage, IGBT overtemperature, module & resistor overtemperature, short circuits, overcurrent, phase loss, asymmetry
Communication Service
Ethernet router
HS Code
8537101190
Origin
Sweden
Condition
Brand New
MOQ
1
Lifecycle Status
Active
Functional Highlights
The BDFC-01C regulates braking by controlling the pulse length of upper-leg IGBTs, ensuring precise resistor connection to the DC link. Operating at 1 kHz with a 120° phase shift, it minimizes DC voltage ripple and enhances system stability.
Continuous monitoring of critical parameters allows the BDFC-01C to protect against faults such as short circuits, overcurrent, and temperature overloads, ensuring safe and reliable operation.
Applications and Compatibility
The ABB BDFC-01C Fan Control Panel is ideal for ACS880 drive systems requiring advanced braking control. It integrates seamlessly into DCS architectures, providing enhanced safety and efficiency in industrial automation.
Its robust protection features and parallel module capability make it a trusted solution for power generation, manufacturing, and heavy-duty industrial applications.
