The ABB CI810V2 is a Field Communication Interface (FCI) designed for the S800 I/O system. It serves as a critical gateway, enabling high-speed communication between the S800 I/O modules and the Advant Fieldbus 100 (AF100) network. This interface facilitates seamless data exchange, allowing the controller to monitor and control distributed I/O points across the industrial automation network.
Features
Supports high-speed communication via the AF100 fieldbus protocol.
Designed for integration with ABB Advant OCS and S800 I/O distributed systems.
Robust construction suitable for demanding industrial environments.
Facilitates efficient, real-time data transmission between field devices and the control system.
Applications
The CI810V2 is typically deployed in large-scale industrial control environments, including power generation, chemical processing, and oil and gas facilities, where reliable distributed I/O communication is essential for system stability.
Technical Specifications
Product Model
CI810V2
Order Code / Spare Model
3BSE013224R1
Function
AF100 Field Communication Interface
System Compatibility
S800 I/O
Tariff Code
8517620050
Installation Guidelines
Ensure the power is disconnected before installing or removing the module from the I/O rack.
The module should be mounted in a clean, dry environment with adequate ventilation to prevent overheating.
Follow standard ESD (Electrostatic Discharge) handling procedures when touching the module components.
Ensure all AF100 bus connections are secure and properly shielded to minimize electromagnetic interference (EMI).
Verify that the module is firmly seated in the base unit to ensure proper electrical contact with the backplane.
FAQ
What is the primary function of the CI810V2? The CI810V2 acts as a communication interface that connects S800 I/O stations to the AF100 fieldbus network, allowing for distributed control and monitoring.
Is the CI810V2 compatible with other fieldbus protocols? No, the CI810V2 is specifically designed for the AF100 protocol. Ensure your system architecture supports this communication standard before installation.
