The ABB 5SHY3545L0009 3BHB013085R0001 IGCT Module is an advanced high‑power semiconductor solution engineered for medium‑voltage applications. It integrates monitoring, diagnostics, and protection functions to ensure reliable performance in demanding power conversion systems such as HVDC transmission, industrial drives, and renewable energy converters.
Technical Specifications
Parameter
Value
Model Number
3BHB013085R0001 5SHY3545L0009
Manufacturer
ABB
Module Type
IGCT Module
System Compatibility
DCS / Advant OCS / 800xA / ACS 6000
Blocking Voltage
4500 V
Surge Current
25–30 kA
Switching Speed
Frequency Support
Up to 500 Hz
Gate Trigger Voltage
1.5–2.5 V
Current Rise Capability
1 kA/µs
Monitoring Functions
Current, voltage, temperature
Interfaces
Ethernet, serial, HMI
Dimensions
35 × 29 × 6 cm
Weight
2.66 kg
HS Code
8537101190
Product Origin
Sweden
Condition
Brand New
Lead Time
In Stock
MOQ
1
Lifecycle Status
Active
Communication Service
Ethernet router
Functional Description
The ABB 5SHY3545L0009 3BHB013085R0001 IGCT Module delivers precise switching management with rapid transition times and robust surge current handling. Its integrated diagnostics provide immediate fault detection, while multiple communication interfaces and intuitive HMI simplify configuration and monitoring. Designed for harsh industrial environments, it ensures long‑term reliability and optimized performance in high‑power applications.
