ABB 5SHX08F4502 Asymmetric IGCT Module
No reviews
In stock!
- Part Number: ABB 5SHX08F4502
- Brand: ABB
- Type: Asymmetric IGCT Module
- Dimensions: 116x2.5x2cm
- Country of Origin: USA
- Barcode: 8537101190
Share
Additional Specifications
| Color / Pattern |
|
| Power Source |
|
| Communication Protocols |
|
| Controller Design |
|
Product Description
The ABB 5SHX08F4502, also cataloged as the ABB 5SHX08F4502 Asymmetric IGCT Module, operates as a dedicated hardware component for high-power switching execution within AC Drives and traction system networks.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 5SHX08F4502 |
| Brand | ABB |
| Origin | Switzerland (CH) |
| Weight | 2.9 kg |
| Dimensions | Standard housing matching 4500 V asymmetric press-pack specifications |
| Operating Temp | -40 to +125 deg C (Standard industrial semiconductor junction boundaries) |
| Power Consumption | Monitored and supplied via fiber optic gate drive power rail |
| Voltage Rating (VDRM) | 4500 V |
| Control Interface | Direct fiber optic link |
| Turn-On Delay (tdon) | Less than 3 us |
| Turn-Off Delay (tdoff) | Less than 6 us |
| Turn-Off Jitter (tdoff jitter) | Less than 800 ns |
| Silicon Architecture | Free-floating silicon technology |
| EMI Immunity | Verified high immunity profile |
| Cosmic Radiation Tolerance | Rated for sea-level operating baselines |
Firmware Flash Compatibility and I/O Density Scaling
The control infrastructure of this asymmetric module relies on a direct fiber optic interface to manage signal scaling and eliminate electromagnetic interference (EMI). To handle the high-velocity switching loops without execution faults, the master drive controller must run a validated firmware flash compatibility profile. This firmware alignment ensures the turn-on delay (under 3 us) and turn-off delay (under 6 us) remain strictly bounded, keeping the turn-off jitter below 800 ns to provide deterministic, snubberless commutation.
Frequently Asked Questions
Q: What is the primary benefit of the free-floating silicon technology used in this module?
A: Free-floating silicon technology eliminates the solid metallurgical bonding between the silicon wafer and the adjacent molybdenum disks. The components are held together purely by external mechanical clamping force, which drastically improves thermal cycling life and electrical efficiency by allowing unrestricted expansion and contraction during thermal transitions.
Q: Why does this module utilize a fiber optic control interface instead of standard copper pins?
A: A fiber optic interface provides absolute galvanic isolation between the low-voltage control electronics and the 4500 V high-power circuits. This layout yields exceptionally high EMI immunity and allows precise gate timing execution without signal degradation from high-voltage transients.
Q: How does cosmic radiation tolerance factor into the operation of the device?
A: High-voltage semiconductors are susceptible to single-event burnouts (SEB) caused by cosmic ray particles. This module is structurally optimized to maintain its 4500 V rating at sea-level atmospheric densities, though de-rating parameters must be applied if the unit is installed at high altitudes.
