Configured for high-power switching execution in AC Drives networks, the ABB 5SHX0660F0002 (3BHB018104R0001 RC-IGCT Module) provides direct physical/electrical execution.
Hardware Specifications
Parameter
Specification
Model
5SHX0660F0002
Brand
ABB
Origin
Switzerland (CH)
Weight
2.9 kg
Dimensions
Standard press-pack housing dimensioned for 3300 V DC applications
Operating Temp
-40 to +125 deg C
Power Consumption
Regulated by external gate unit power distribution networks
Voltage Rating
3300 V DC
Current Rating
660 A continuous
Switching Frequency
Up to 500 Hz
Thermal Resistance
Approx. 0.03 K/W junction-to-case
Isolation Voltage
Equal to or greater than 10 kV
Mounting Type
PCB-mounted
Cooling Method
Liquid or forced air
Alternative Part Identifier
3BHB018104R0001
Firmware Flash Compatibility and I/O Density Scaling
The device integration utilizes high-power density scaling to interface directly with control boards across the internal drive topology. Correct gate command execution requires strict firmware flash compatibility matching between the drive controller and the integrated gate control circuitry to handle high-frequency 500 Hz switching loops. This alignment ensures deterministic control over conduction transitions, preventing timing drift or mismatch faults that degrade reverse-conducting thyristor switching sequences.
