Configured for high-power switching execution in AC Drives networks, the ABB 5SHX0445D0001 (5SHX0445D0001 IGCT Module) provides direct physical/electrical execution.
Hardware Specifications
Parameter
Specification
Model
5SHX0445D0001
Brand
ABB
Origin
Switzerland (CH)
Weight
1.51 kg
Dimensions
38 mm (Wafer diameter)
Operating Temp
0 to 65 deg C (Standard junction boundary limits)
Power Consumption
Regulated by gate driver logic circuit
Core Performance Rating
4.5 kV peak blocking voltage
Coating
Coated passivation layer
Customs Tariff Number
85413000
Alternative Part Identifier
3BHL000382P0101 / 3BHB004027R0101
Firmware Flash Compatibility and Deterministic Switching
This component utilizes integrated gate-commutated thyristor architecture requiring precise gate driver pulse synchronization. Firmware flash compatibility across the control platform ensures that the gate turn-off parameters match the deterministic switching frequencies of the main inverter backplane. The internal semiconductor matrix functions with zero latency during high-current transitions, regulating power density scaling and suppressing transient harmonics across the internal power bus.
