ABB 560CMR02 1KGT036300R0001 | RTU560 Module

Product Description

The ABB 560CMR02 (1KGT036300R0001) serves as a high-performance communication unit and processing node engineered for RTU560 racks. It coordinates real-time telemetry routing between distributed I/O substations, plant HMIs, and wide-area master networks.

Technical Specifications

• Brand: ABB
• Product Series: RTU560 Telecontrol Infrastructure
• Model Number: 560CMR02
• Order Code: 1KGT036300R0001
• Core Processing Unit: 32-bit ARM Cortex A8 processing engine operating on an AM3352 platform
• Network Media Links: 2x 10/100BaseT Fast Ethernet interfaces running TCP/IP or Modbus TCP arrays
• Serial Interfaces Matrix: 6x RS-232C/RS-485 selectable communication channels
• Serial Baud Range: Scalable serial bit rate from 200 bit/s to 38.4 kbit/s over RS-485 linkages
• Local Maintenance Port: 1x Micro-USB Type B device connection running up to 480 Mbit/s
• Sub-Bus Architecture: 1x Serial Peripheral Bus (SPB) link dedicated to local peripheral I/O tracking
• Chronological Sync Basis: Internal real-time clock (RTC) featuring independent battery-buffered power
• Mechanical Factor Profile: 3HE Euro card standard layout matching an 8R front panel face
• Rack Allocation Footprint: Slotted directly into RTU560 subracks, occupying two full slots
• Main Feed Potential: 24 V DC operational nominal rating
• Active Thermal Demand: Optimized low power footprint consuming approximately 5 W under load
• Thermal Operating Bounds: Reliable performance from -20 to +60 degrees Celsius active window
• Thermal Storage Bounds: Protection from exposure between -40 and +70 degrees Celsius limits
• Moisture Coefficient Range: 5% to 95% relative non-condensing humidity limits
• Ingress Shielding Profile: IP20 touch-proof structural enclosure rating
• Compliance Standards: Fully certified under IEC 61131-2 and IEC 61850 grid automation metrics
• Depth: 20.3 cm
• Height: 5.8 cm
• Width: 14.0 cm
• Net Weight: 0.215 kg

Industrial Application Scenarios

This machine-slotted communication board mounts inside centralized remote terminal units and substation distribution racks to translate raw Modbus or Profibus field data into standardized TCP/IP arrays, maintaining uninterrupted system telemetry and process precision synchronization across thermal generation facilities.
