The ABB 3BHB030310R0001 5SHY4045L0006 IGCT Module delivers advanced power semiconductor technology for medium‑voltage drives and conversion systems. Its compact design combines high blocking voltage, rapid switching, and robust thermal management for demanding industrial applications.
Technical Specifications
Parameter
Value
Model Number
3BHB030310R0001 5SHY4045L0006
Manufacturer
ABB
Module Type
IGCT Module
System Compatibility
DCS / Advant OCS / 800xA
Blocking Voltage
4500 V
Peak Surge Current
30 kA
Switching Times
Frequency Support
Up to 500 Hz
Trigger Voltage
1.5–2.5 V
Gate Current
50 A
Operating Temperature
-40°C to +125°C
Storage Temperature
-40°C to +140°C
Thermal Resistance
Optimized low resistance
Dimensions
35 × 29 × 6 cm
Weight
2.64 kg
HS Code
8537101190
Product Origin
Sweden
Condition
Brand New
Lead Time
In Stock
MOQ
1
Lifecycle Status
Active
Communication Service
Ethernet router
Functional Description
The ABB 3BHB030310R0001 5SHY4045L0006 achieves precision switching with <5µs turn‑on and <10µs turn‑off times. Its integrated gate drive supports 50A gate current, ensuring robust control in high‑power environments. The press‑pack design enhances mechanical stability under vibration and thermal cycling, while military‑grade materials guarantee durability.
Applications and Compatibility
The ABB 3BHB030310R0001 5SHY4045L0006 IGCT Module suits steel mill drives, mining equipment, renewable energy inverters, and ACS 2000 drive systems. Engineers value its high surge current capacity, fast switching, and optimized thermal performance, making it essential for next‑generation medium‑voltage applications requiring efficiency and reliability.
