The ABB 216GE61/N222 (HEDG112801R1) functions as an intelligent, high-performance drive control board and digital I/O interface assembly engineered for heavy-duty motor and generator protection networks. This multi-layered processing card executes advanced computational algorithms with real-time feedback alignment, safeguarding heavy industrial powertrains through robust galvanic isolation and continuous microprocessor-driven diagnostics.
Technical Specifications
Brand: ABB
Model Code: 216GE61/N222
Part Reference: HEDG112801R1
Product Classification: Drive Control Board and Digital Input/Output Module
Processing Architecture: High-speed Digital Signal Processor (DSP) dedicated to real-time control loops
Core Control Algorithms: Vector Control and Direct Torque Control (DTC)
Input Supply Potential: 24 V DC operational rating
Isolating Componentry: Onboard input relay assembly configured for trip, alarm, and status conditioning
Network Interface Array: Standard Profibus, Ethernet/IP, and scalable industrial bus communication channels
Hardware Interfacing Compatibility: Tailored for ABB ACS/ACX series drives and REG216 generator protection systems
This dual-function control module mounts directly inside high-voltage variable speed drive cubicles and turbine generator subracks to process encoder feedback, coordinate complex Direct Torque Control profiles, and route isolated safety-trip signals over central industrial networks.
