8408‑005 | Woodward | Digital Governor Control Module

Description

The Woodward 8408‑005 Digital Governor Control Module is a high‑performance unit engineered to regulate turbine and engine speed while managing generator load distribution. It ensures stable parallel operation, efficient load sharing, and system protection in industrial, marine, and utility applications.

Specifications

• Model Number: 8408‑005

• Type: Digital Governor Control Module / Generator Load Control

• Manufacturer: Woodward

• Supply Voltage: 24 VDC nominal (control circuit)

• Frequency Range: 50 Hz / 60 Hz compatible

• Accuracy: Load distribution within ±1%

• Control Functions: Automatic load adjustment, droop control, isochronous load sharing

• Communication Interface: Analog and digital signals for generator integration

• Protection Features: Overload protection, low‑frequency detection, voltage stabilization support

• Cooling Method: Natural convection

• Operating Temperature: −20 °C to +70 °C

• Storage Temperature: −40 °C to +85 °C

• Dimensions: 270 × 180 × 60 mm

• Weight: ~1.3 kg

• Installation: Panel or rack mount in generator control cabinets

• Lifecycle Status: Active, with replacement and upgrade support

Features

• Precise Speed Regulation: Processes frequency inputs from magnetic pickups or proximity sensors for real‑time control.

• Load Sharing Capability: Ensures smooth generator paralleling and balanced load distribution.

• Advanced Algorithms: Digital regulation for stable performance under varying demand.

• System Protection: Built‑in overload and frequency safeguards reduce mechanical stress.

• Versatile Application: Suitable for industrial turbines, marine engines, and utility power systems.

• Compact & Reliable: Rugged design with natural convection cooling for continuous operation.
