The Triconex 3624 Digital Output Module is a supervised triple modular redundant (TMR) unit designed for safety-critical control applications. With 16 commoned output channels, it ensures reliable signal transmission and diagnostic monitoring, supporting high-integrity safety instrumented systems.
Key Technical Specifications
Model / Part Number:3624
Manufacturer: Triconex
Product Type: Digital Output Module
Architecture: TMR (Triple Modular Redundant), Supervised DO
Nominal Voltage: 24 VDC
Voltage Range: 16–30 VDC
Maximum Voltage: 36 VDC
Output Channels: 16, commoned
Voltage Drop: < 1.5 VDC (typical)
Power Module Load: < 10 W
Net Weight: 0.8 kg
Shipping Weight: 2 kg
Application Scenarios
Emergency shutdown (ESD) systems
Fire and gas detection networks
Petrochemical and power generation safety systems
Industrial automation requiring supervised digital outputs
FAQ
Q: How many outputs does the 3624 provide? A: It supports 16 supervised digital output channels.
Q: What is the benefit of supervised outputs? A: Supervision ensures that output signals are continuously monitored for integrity, reducing the risk of undetected failures.
Q: Can the module operate beyond 30 VDC? A: The maximum supported voltage is 36 VDC; exceeding this may damage the module.
