3300/03-02-00 89998-01 | Bently Nevada | System Monitor Module

Product Overview

The Bently Nevada 3300/03‑02‑00 89998‑01 System Monitor Module provides centralized monitoring and diagnostics for 3300 Series racks. It ensures reliable system operation by supervising module health, power distribution, and communication integrity.

Technical Specifications

• Manufacturer: Bently Nevada

• Series: 3300 Monitoring System

• Model Number: 3300/03‑02‑00 89998‑01

• Type: System Monitor Module

• Application: Supervises rack modules, power, and communication

• Functions: Health monitoring, alarm management, diagnostics

• Installation: Rack‑mountable module board

• Operating Environment: Industrial grade, continuous operation

Model Code Breakdown

• 3300/03: Identifies the product family as part of the 3300 Series system monitoring line.

• 02: Defines configuration for monitoring functions.

• 00: Standard rack mounting option.

• 89998‑01: Factory configuration code specifying diagnostics and communication features.

Installation & Wiring Guide

• Rack Positioning: Install in designated slot within the 3300 Series rack.

• Power Monitoring: Connect to rack power supply for supervision.

• Communication: Ensure proper wiring to system interface for diagnostics.

• Grounding: Proper grounding required to minimize electrical noise.

• Maintenance: Hot‑swappable design allows replacement without shutting down the rack.

FAQ

Q: What does the System Monitor Module supervise? A: It monitors rack power, module health, and communication integrity.

Q: Is this module required for all 3300 racks? A: Yes, it is essential for centralized monitoring and diagnostics.

Q: Can the module be replaced without shutting down the rack? A: Yes, it is hot‑swappable.

Q: Does it integrate with legacy Bently Nevada racks? A: Fully compatible with 3300 Series rack assemblies.
