The Allen‑Bradley 2711P‑T10C6D1 is a PanelView Plus 1000 touchscreen HMI terminal featuring a 10.4‑inch color display, multiple communication ports, and FactoryTalk View ME runtime support for machine‑level visualization.
Specifications
Manufacturer: Allen‑Bradley / Rockwell Automation
Model: 2711P‑T10C6D1
Series: PanelView Plus 1000
Display Type: 10.4‑inch color TFT
Resolution: 640 × 480 (VGA)
Input Method: Resistive touchscreen
Backlight: Replaceable CCFL
Power: 24 VDC
Communication Ports: Ethernet, RS‑232, ControlNet
Memory: Internal RAM + CompactFlash storage
Software Support: FactoryTalk View ME runtime
Enclosure Type: Panel‑mount
Temperature Range: 0°C to +55°C
Applications: Machine‑level HMI, visualization, operator control
Features
Touchscreen Operation: Direct operator interaction for machine control
Color TFT Display: Clear visualization of alarms, trends, and process data
Multiple Communication Ports: Ethernet, RS‑232, and ControlNet connectivity
FactoryTalk Integration: Supports FactoryTalk View ME applications
Panel‑mount Design: Suitable for industrial operator stations
Industrial Durability: Designed for continuous operation in harsh environments
FAQ – Common Questions
What_is_the_function: It provides touchscreen HMI visualization and operator control.
Does_it_support_ControlNet: Yes, the “C6” communication code includes ControlNet.
Is_it_touchscreen_only: Yes, this model has no keypad.
What_software_is_required: FactoryTalk View ME.
Where_is_it_used: Machine‑level automation and operator interface panels.
