The Modicon Momentum 170ADI34000 discrete input base is designed for reliable integration within the Schneider Electric Momentum automation platform. This module provides 16 DC input channels grouped into a single block, ensuring efficient signal acquisition for industrial control systems.
Isolation: 500 V AC insulation between channels and bus
Local Indicators: 16 LEDs for channel status monitoring
Dimensions: Height 141.5 mm | Width 125 mm | Depth 47.5 mm
Net Weight: 0.19 kg
Protective Treatment: TC standard coating
Certifications: CE marked
Terminal Assignments
Inputs: IN_DIS#1 through IN_DIS#16
Power Supply: L+ (PW_POS), M- (PW_NEG)
Terminal Block: TB
Application Scenarios
This module is ideal for discrete signal monitoring in manufacturing automation, process control, and distributed I/O systems. It is commonly used in applications requiring compact, modular input bases with clear LED diagnostics.
FAQ
Q: Can this module be used with AC signals? A: No, it is specifically designed for DC discrete inputs within the range of -3 to 30 V.
Q: How is channel status monitored? A: Each input channel has a dedicated LED indicator for real-time diagnostics.
Q: What insulation level is provided? A: 500 V AC isolation between input channels and the system bus ensures safe operation.
