16925-17 Bently Nevada Interconnect Cable

Product Description

The 16925-17 is a high-performance signal transmission cable engineered by Bently Nevada for demanding machinery protection systems. Designed primarily for use with 330400 and 330425 accelerometers, this cable ensures the precise delivery of casing acceleration data in critical applications like gear mesh monitoring. Its shielded 22 AWG construction is optimized to maintain signal purity and meet the rigorous API 670 standards required in the petroleum and power generation sectors.

Technical Specifications

• Manufacturer: Bently Nevada

• Model Number: 16925-17

• Cable Configuration: 3-Conductor Shielded

• Wire Gauge: 22 AWG (0.5 mm²)

• Termination End A: 3-Socket Female Plug

• Termination End B: Terminal Lugs

• Standard Length: 17 Feet (Specified by -17 Suffix)

• Length Range Capacity: 2.0 ft to 99 ft (0.6 m to 30 m)

• Compatible Sensors: 330400 (100 mV/g) and 330425 (25 mV/g) Accelerometers

• Standard Compliance: Designed for API 670 requirements

• Signal Support: High-fidelity transmission for gear mesh and vibration monitoring

• Insulation Integrity: Industrial-grade shielding for EMI/RFI rejection

Operational Applications

This cable assembly is essential for:

• API 670 Compliance: Integrating vibration sensors into standardized machinery protection frameworks.

• Gearbox Monitoring: Capturing high-frequency acceleration data in complex gear mesh systems.

• Extreme Environments: Reliable connectivity for sensors operating in high-amplitude vibration zones (up to 75 g peak).
