147663-01 | Bently Nevada | VGA Display I/O Module

Description

The Bently Nevada 147663-01 is the rear I/O module for the 3500/94 VGA Display System. It serves as the physical interface between the 3500 rack and a standard color VGA monitor, utilizing touch-screen technology to display comprehensive machinery protection data. This module converts internal rack information into an RGB analog signal for local visualization of machinery health.

Specifications

• Model Number: 147663-01
• Product Type: VGA Display I/O Module (Internal Terminations)
• Compatible Monitor: 3500/94 VGA Display Module
• Output Signal: Analog Red, Green, Blue (RGB) and Sync signals
• Communication Port: RS232 port for touch-screen controller data
• Display Support: Supports up to two displays per 3500 rack
• Operating Temperature: -30°C to +65°C (-22°F to +150°F)
• Dimensions: 241.3 mm x 24.4 mm x 99.1 mm
• Net Weight: 0.34 kg (0.75 lb)
• Shipping Weight: 2 kg

Features

• Touch-Screen Integration: Fully supports touch-screen controllers via the RS232 interface, allowing operators to navigate menus and query data directly at the display.
• API-670 Compliance: Provides a dedicated "3300-style" rack view screen featuring bar graphs and numerical values to meet industry safety standards.
• Customizable Screens: Allows users to configure up to nine custom display screens locally to group specific data types like 1X measurements or Gap values.
• Extended Distance Support: Capable of driving a display monitor up to 8 meters (25 feet) away from the rack using standard cabling.
• Real-Time Visuals: Displays the System Event List, Alarm Event List, and OK/Bypass status for all modules and channels within the rack.
• Flexible Mounting: Works with various display mounting options including 19-inch EIA rack, panel, or independent mounts.
• Comprehensive Diagnostics: Includes a front-facing OK LED and TX/RX LEDs to provide immediate status of module health and system communication.
