The Bently Nevada 138607-01 3500/22M Standard Transient Data Interface (TDI) Module is a key component of the 3500 Series machinery protection and monitoring system.
Module Type: Standard Transient Data Interface Module
Condition: Brand New
System Compatibility: Bently Nevada 3500 Series Machinery Protection System
Product Range: 3500/22M TDI
Dimensions: Standard 3500 rack slot size
Weight: Approx. 0.45 kg
HS Code: 8537101190
Origin: USA
Lead Time: In Stock
MOQ: 1
Operating Temperature: 0 to 60°C
Storage Temperature: -40 to 85°C
Power Supply: 24 VDC (from rack backplane)
Communication: Ethernet (via System Communications Processor)
Functions:
Transient data capture and storage
Interface between 3500 modules and external analysis software
Event-triggered waveform recording
System diagnostics and configuration support
Functional Highlights
Provides transient data acquisition for machinery diagnostics and root cause analysis.
Interfaces with external software for advanced vibration and condition monitoring.
Supports event-triggered waveform capture for detailed machinery health assessment.
Hot-swappable design allows replacement without system shutdown.
Ensures reliable communication across the 3500 rack system.
Application Scenarios
Turbomachinery monitoring in power generation plants.
Oil & gas facilities requiring advanced vibration diagnostics.
Petrochemical industries with critical rotating equipment.
Manufacturing plants needing transient event analysis for predictive maintenance.
FAQ
Q: What is the primary function of the 3500/22M TDI module? A: It captures transient data and provides communication between the 3500 rack and external analysis systems.
Q: Can the module be replaced under power? A: Yes, it is hot-swappable and can be replaced without shutting down the rack.
Q: Which systems is it compatible with? A: It is designed for use with the Bently Nevada 3500 Series machinery protection system.
